Lub Toughest Retort Zaj duab xis nrog Nylon Reinforcement
PET AL PA RCPP laminated zaj duab xis yog plaub- txheej txheej: PET, aluminium ntawv ci, PA (nylon), thiab RCPP. Cov txheej nylon yog qhov tseem ceeb - nws muab kev tiv thaiv tshwj xeeb, ua rau cov yeeb yaj kiab no zoo tagnrho rau cov khoom siv nrog cov pob txha ntse lossis cov plhaub. RCPP txheej tiv thaiv retort sterilization ntawm 121 degree. Jiangsu Dino tau pib tsim cov yeeb yaj kiab no hauv xyoo 2021. Peb lub chaw muaj 75,000 m² nrog 160,000 m² ntawm plua plav- kev cob qhia pub dawb. Peb ntiav ntau tshaj 300 tus neeg, suav nrog cov kws tshaj lij hauv kev ntim khoom rov qab. Peb muaj kev paub dhau los hauv kev sib txuas nylon rau ntawv ci yam tsis muaj kev cuam tshuam cov khoom thaiv.
Rau Retort Cov Khoom Uas Sib Tw Rov Qab
Kev ntim cov nqaij siav nrog cov pob txha lossis nqaij nruab deg nrog cov plhaub yog qhov nyuaj. PET AL PA RCPP laminated zaj duab xis daws qhov no. Cov txheej nylon tiv thaiv punctures thaum lub sij hawm txhaws, retort, thiab tuav. Aluminium ntawv ci muab qhov thaiv tsis pub muaj oxygen thiab lub teeb, khaws cia cov zaub mov saj thiab xim. RCPP txheej seals ruaj ntseg txawm tias tom qab lub siab - cua sov retort voj voog. Cov yeeb yaj kiab no yog siv rau stews, pob txha- hauv cov kua zaub, cov nqaij npuas, thiab cov zaub mov npaj txhij uas xav tau lub neej ntev ntev yam tsis muaj tub yees. Rau cov neeg yuav khoom, zaj duab xis no ua rau txo cov pob tsis ua haujlwm. Nws kuj tseem tso cai rau koj lub hom phiaj kom muaj txiaj ntsig zoo, txee- cov zaub mov ruaj khov uas cov neeg siv khoom tuaj yeem ua kom sov thiab noj ncaj qha los ntawm lub hnab.
Ordering thiab Manufacturing Details
Peb tsim PET / AL / PA / RCPP cov yeeb yaj kiab uas siv yim lub tshuab laminating thiab peb lub tshuab luam ntawv rotogravure. Qhov siab tshaj plaws luam ntawv thiab slitting dav yog 1,200 hli; hnab qhov ntev yog raws li peb tus qauv siab tshaj plaws dav specifications. Peb muab cov khoom lag luam hauv ob qho tib si yob Tshuag thiab ua ntej- ua lub hnab hom. Yam tsawg kawg nkaus kom muaj nuj nqis (MOQ) yog 500 kg rau yob Tshuag thiab 200,000 units rau lub hnab. Khoom thickness tuaj yeem kho raws li qhov kev thov. Lub sij hawm ua tus qauv yog 15-20 hnub ua haujlwm; Cov kev cai txiav txim tiav tsis pub dhau 15-25 hnub ua haujlwm tom qab kev pom zoo ua qauv, thaum lub sij hawm ua cov lus txiav txim rov qab tuaj yeem luv luv los ntawm 3-5 hnub. Peb muab cov qauv dawb rau cov khoom txheem; tus nqi siv rau cov qauv kev cai, uas tuaj yeem thim rov qab los ntawm kev txiav txim ntau tus nqi ntawm RMB 200,000 lossis ntau dua.
Quality Assurance for High -Kev Ua Yeeb Yam Yeeb Yam
Peb sim PET AL PA RCPP laminated zaj duab xis dav. Peb ntsuas OTR thiab WVTR, foob lub zog ua ntej thiab tom qab retort, puncture resistance, thiab foil kev ncaj ncees. Peb kuj tshawb xyuas nylon adhesion. Peb qhov system zoo yog ISO9001 thiab ISO22000 tau ntawv pov thawj. Peb muaj tag nrho cov ntawv tso cai tsim nyog. Peb lees txais kev txheeb xyuas thib peb - tog. Peb muab cov lus qhia ntxaws ntxaws nrog txhua pawg. Ib xyoos ib zaug CMA hom kev xeem ntawv tshaj tawm kuj muaj. Peb tom qab- pab pawg muag khoom teb hauv 24 teev. Peb muab 12 lub hlis lav tiv thaiv cov khoom tsis xws luag. Yog tias peb muaj lub luag haujlwm, peb hloov lossis thim nyiaj rov qab. Peb khaws cov khoom ruaj ntseg thiab muaj cov kab lamination thaub qab kom ntseeg tau tias xa khoom.
Technical Specifications
|
Parameter |
Specification |
|
Khoom siv |
PET AL PA RCPP plaub- txheej laminate |
|
Sab hauv txheej |
RCPP |
|
Daim ntawv khoom |
Yob zaj duab xis / tiav hnab (txhua hom) |
|
MOQ |
Yob zaj duab xis: 500 kg / Pouches: 200,000 pcs |
|
Thickness |
Customizable |
|
Kev luam ntawv |
Gravure, mus txog 10 xim |
|
Max Printing Dav |
1200 hli |
|
Max Slitting Dav |
1200 hli |
|
Max Pouch Dav |
Peb- sab foob: 500 hli / Yim- sab foob: 600 hli / Stand-up & chaw foob: 300 hli |
|
Daim ntawv thov |
Stews, pob txha-hauv cov kua zaub, nqaij npuas, txee- cov zaub mov ruaj khov |
|
Lub Sijhawm Lead (Standard) |
15-20 hnub ua haujlwm tom qab tso nyiaj |
|
Lub Sijhawm Lead (Custom) |
15-25 hnub ua haujlwm tom qab kuaj pom zoo + tso nyiaj |
|
Rov ua dua Lub Sijhawm Lead |
3-5 hnub ua haujlwm luv luv |
|
Warranty |
12 lub hlis txij li hnub xa khoom |
|
Keeb kwm |
Suqian, Jiangsu, Suav teb |
|
Cia |
Ntxuav, qhuav, ventilated, Tsawg dua los yog sib npaug rau 65% av noo, Ntau tshaj los yog sib npaug rau 1m los ntawm tshav kub |
|
Txee lub neej |
12 hli |
